British Federal Spot welder

[gormleyman46]

Does anyone know how to set the microPac 8 on an british federal spot welder.



[Robotstar5]

Does anyone know how to set the microPac 8 on an british federal spot welder.

Probably, can you post a picture of it to remind me which one it is.



[gormleyman46]



[500e]

http://www.britishfederal.com/literature.html
Or
British Federal also offers a comprehensive spares history including machine and electronic timer control manuals, Bill of Material and full manufacturing drawings for all previously manufactured British Federal machines.
We can provide consumable or machine spares for the whole range of British Federal products dating back some 40 years.
Kingswinford DY6 7FQ
Phone:01384 455401
Try phone



[Robotstar5]

Been a few years, but here goes...
Turn PROG SEL to any number (not robot)
Toggle switch in PROG position
Each press of SEQ will move through weld sequence which is usually PSQ, SQ, WELD, HOLD, OFF, HEAT
Then use tens & units buttons to alter times
PSQ - pre squeeze = time to close tips
SQ - squeeze = time to squeeze parts together
WELD = time weld is on in cycles
HOLD = time for weld to start cooling (also known as forge time)
OFF = time before next weld allowed (used when repeating)
HEAT = weld current (normally a %)
Depending on model there may be H1, H2 (HEATs) or PULSE for various applications
Switch toggle back to run

Sorry no guarantees on the above, it's been 20+ years since I played with them

Found some info here to read and will have a look to see if I still have the schematics/drawings for the MP8



[gormleyman46]

That's great. Thanks



[Robotstar5]

Sorry, no luck with documentation for MP8, could only find stuff for MP16 & MP2000, looks like I can program & calibrate the MP2000



[gormleyman46]

She is a British federal 65kva. I have her going but she isn't putting a lot of power to the tips. Any ideas??? Thanks



[Robotstar5]

Is it a pedestal spot welder similar to this or a pendant (hand held) type welder?
