Flasher relay

[Fazerruss]

Hi all, I'm after a little help from the collective. I need a neat easy solution to make a couple of 12 LEDS flash for my crane projet. I could build a flasher using a 555 timer but this will use up time I don't really have with the Xmas deadline fast approaching.

The criteria is cheap, quick delivery and silent running so solid state device.

So ideally I'd like to use something like this http://www.ebay.co.uk/itm/272345314231 but I'm not familiar with 2 wire flasher relays. do they just wire in series with the load or am I missing something?

Thanks



[steveo3002]

you know you can get ones that flash without any add on's? would that do?



[cumbriasteve]

Wife got a string of Christmas deco led's from the £ shop, they seem to flash well, 3 x AA batteries, perhaps whatever is controlling them will do you, think they had several versions.



[rikrobson]

the 555 option should tale less than an hour. there will be thousands of circuits to choose from.
Or get Xmas tree lights



[Robotstar5]

To use the unit you linked to, connect "B" to +12V supply, "L" to + side of LEDs (wire LEDs in parallel) and - side of LEDs back to - (0V) supply.



[Fazerruss]

To use the unit you linked to, connect "B" to +12V supply, "L" to + side of LEDs (wire LEDs in parallel) and - side of LEDs back to - (0V) supply.

Ah so it is in series, I'll go for that then.

you know you can get ones that flash without any add on's? would that do?

That was my preference but no one seems to do 10mm amber flashing LEDs



[steveo3002]

http://www.ebay.co.uk/itm/DRONE-LED...hash=item58e09d1c80:m:mhGkLrqPvF649aTBwxFeJAQ

not 12v but prob fit a resistor



[rtbcomp]

The flasher unit in the OP may make a clicking noise though. Not sure about bikes, but car indicators have to have an audible warning, normally generated in the flasher. Might be as well to ask.



[mr migwire]

use these, ive used them on various projects and they do the job fine... http://www.ebay.co.uk/itm/Qty-5-5mm...hash=item1c22df2465:m:mHkaSuJTfavN0jpeNCPhUUA



[the snooper]

Be aware that you need a 0.05 amp draw to make it work, if you don't have enough led's to draw it, it won't work

Hi all, I'm after a little help from the collective. I need a neat easy solution to make a couple of 12 LEDS flash for my crane projet. I could build a flasher using a 555 timer but this will use up time I don't really have with the Xmas deadline fast approaching.

The criteria is cheap, quick delivery and silent running so solid state device.

So ideally I'd like to use something like this http://www.ebay.co.uk/itm/272345314231 but I'm not familiar with 2 wire flasher relays. do they just wire in series with the load or am I missing something?

Thanks



[Fazerruss]

use these, ive used them on various projects and they do the job fine... http://www.ebay.co.uk/itm/Qty-5-5mm...hash=item1c22df2465:m:mHkaSuJTfavN0jpeNCPhUUA

These are only 5 mm though. I need 10mm diameter



[Fazerruss]

Be aware that you need a 0.05 amp draw to make it work, if you don't have enough led's to draw it, it won't work

I'm going to run about 3 or 4 and hopefully 10mm may pull enough.
I have the LEDs already so I'll stick my DMM in line to check.



[Robotstar5]

Be aware that you need a 0.05 amp draw to make it work, if you don't have enough led's to draw it, it won't work

10mm 12V LED's will probably draw about 25mA (0.025A) each so 2 or more should be enough



[the snooper]

If not simple flip flop circuits are easy to knock up which would give two different flashes and only use 6 cheap components

I'm going to run about 3 or 4 and hopefully 10mm may pull enough.
I have the LEDs already so I'll stick my DMM in line to check.



[steveo3002]

did you see my link for flashing orange?



[steveo3002]

also might be of use
http://www.ebay.co.uk/itm/Police-Pa...233ed7b&pid=100005&rk=3&rkt=6&sd=400947145077


http://www.ebay.co.uk/itm/1-10-RC-C...id=100005&rk=2&rkt=6&mehot=pp&sd=311360580906



[langy]

Just use a car electronic flasher unit 2 pin, that's what there for



[mr migwire]

These are only 5 mm though. I need 10mm diameter

like these... http://www.ebay.co.uk/itm/Qty-10-10...hash=item1c73672fa7:m:mel44cU6JsCcQ_TLUfQyJ-Q



[Fazerruss]

like these... http://www.ebay.co.uk/itm/Qty-10-10...hash=item1c73672fa7:m:mel44cU6JsCcQ_TLUfQyJ-Q

Wish I'd seen them before I ordered the others.

Ill go for the relay then they'll all flash together



[daleyd]

This should do you - I've knocked a really simple flasher up to flash a couple of leds on and off, it's almost finished. Feel free to copy the design, it's pretty simple and the program is only about 8000 lines long. No need for any of that fancy eBay nonsense.
